Hush-Panel 33 is a versatile and high-performing acoustic floorboard designed for use in timber frame development. It meets all UK Building Regulations requirements, including Approved Document E (England & Wales), Section 5 (Scotland), and Part G (Northern Ireland). In addition to meeting these standards, Hush-Panel 33 also achieves the performance targets for timber frame development set by Robust Details.

Hush-Panel 33 is a 33mm thick floorboard that is easy to install and quick to use. It is made up of three layers: 18mm High Density P5 Moisture Resistant Chipboard, 10mm Hushfelt TM Resilient Layer, and 5mm Hush Barrier Mat. This unique composition makes it a versatile and economical panel for impact sound insulation between separating floors.

It is suitable for both refurbishment and new build projects and can be used to create a floating floor over concrete and timber or directly over timber joists*. It is compatible with a range of Hush-Systems and can achieve Robust Details Performance levels in timber frame development. To ensure proper installation, the board joints should be bonded with Hush Bond Panel Adhesive.



"Please note: Due to this product being FSC regulated, we are unable to accept returns. Kindly ensure your order is accurate before placing."



Specifications

• Overall Board Dimensions: 2400x600x33mm
• Overall nominal thickness: 33mm
• Board density: 26 kg per board
• Must be used with the Hush RD Flanking strip
• The board joints to be bonded with Hush Bond Panel Adhesive
• Layer: 5mm Hush Barrier Mat.

Performance

Acoustic Performance - Typical Results*:

• Impact: 48 dB
• Airborne: 58 dB
• CTR: 56 dB

*These results are based on the use of Hush-Panel 33 in a timber frame application.

Test Data:

We can provide test data for field tests in compliance with Building Regulations Document E and laboratory tests complying with Robust Details upon request.

Features and Benefits

• Versatile and economical: Provides impact sound insulation between separating floors.
• Suitable for various projects: Can be used for refurbishment and new build projects, and can create a floating floor over concrete and timber or directly over timber joists*.
• Compatible with Hush-Systems: Works well with a range of Hush-Systems for enhanced acoustic performance.
• Meets Building Regulations: Complies with Building Regulations Part E (England and Wales), Section 5 (Scotland), and Part G (Northern Ireland) for acoustic performance.
• Robust Details Performance: Can achieve Robust Details Performance levels in timber frame development, ensuring high-quality sound insulation.
• Easy installation: Can be easily installed in a single time-saving operation, reducing labor and installation time.
• Peel Clean version available: Offers a Peel Clean version for spotless handovers, ensuring a clean and professional finish.
• High performing: Provides excellent acoustic performance, reducing noise transmission and enhancing overall comfort and privacy.
• Durable and long-lasting: Made from high-quality materials, ensuring durability and longevity.
• Environmentally friendly: Manufactured using sustainable materials, contributing to a greener and more sustainable construction industry.

Applications

• Residential Buildings: Hush Panel 33 is ideal for use in residential buildings where noise reduction is required. It can be used in apartments, houses, and condominiums to reduce the transmission of impact and airborne sound.
• Commercial Buildings: This product is also suitable for use in commercial buildings such as offices, restaurants, and hotels. It can help to create a quieter and more comfortable environment for both employees and customers.
• Educational Institutions: Schools, colleges, and universities can benefit from the use of Hush Panel 33. It can help to reduce noise in classrooms, lecture halls, and libraries, enhancing the learning environment.
• Healthcare Facilities: In hospitals, clinics, and other healthcare facilities, noise control is crucial. Hush Panel 33 can help to create a quieter and more peaceful environment for patients and staff.
• Recording Studios: Hush Panel 33 is perfect for use in recording studios. It can help to reduce the transmission of unwanted noise and vibrations, ensuring a cleaner and clearer sound recording.
• Industrial Buildings: In industrial settings, noise can be a significant issue. Hush Panel 33 can help to reduce the transmission of noise, improving the working environment for employees.

Installation

Fitting Instructions:

Full fitting instructions are supplied with all products and can be downloaded from the Installation Guides section.

Certifications

• Approved Document E (England & Wales)
• Section 5 (Scotland)
• Part G (Northern Ireland)

Equivalent/Related Products

• Karma/SIG/CMS Danskin/Regupol - CMS Danskin Sounddeck Extra 30
• JCW - Acoustic Deck 30c/Acoustic Deck 33c/Acoustic Deck 34c
• Floorscan/Sound Insulation Store - dB Panel 33
• Soundproofing Store - N/A

Equivalent Brands

• Sound Barrier - SB Range

About Hush Acoustics

Hush Acoustics is a leading manufacturer of acoustic products for the construction industry. With a focus on innovation and quality, Hush Acoustics provides solutions for soundproofing and noise control in various applications. Their products are designed to meet and exceed industry standards, ensuring optimal acoustic performance and customer satisfaction.
